IN-LINE Brake Sensors.

Electrical Spec Brushless DC 3-phase 9MOSFET square wave controller with hall sensing for smooth control and acceleration. 22A Max output current, 15A rated current.
Mechanical Spec Internally geared motor with a freewheel mechanism to provide low-drag riding. 6:1 reduction ratio for high torque low-drag riding.
Spoke 36 silver spokes with double walled alloy rim
Wheel Types Available in 16" (Brompton) or 20" (Dahon)
Axle The Swytch motor 500W has a solid axle with 10mm diameter - it can be easily filed down to 8 or 9mm for quick release forks.
Brake Compatibility The Swytch 500W motor wheel is compatible with both rim brakes and disk brakes.
Brake Sensors The standard easy-fit brake sensors work with any wired brakes. If you have hydraulic brakes on your bike, you can purchase some Hydraulic brake sensors on our website.
Pedal Sensor The easy fit sensor shown in our product videos can be installed instantly and is compatible with most bicycles. See our accessories for more pedal sensor options.
Power Pack Fully waterproof design with taped seams and rubber socket for USB output. Custom designed and patented Swytch bracket with integrated sliding contact connectors. Provided with spacer rubber rings to enable compatibility with all handlebars sizes. On-Off button 5 level power assist Front light switch on-off 6kph walk mode.
Battery Spec

10Ah 360Wh Lithium-Ion battery with 30A BMS

High quality LG branded 18650 Cells 2500mAh Charge time 3 hours.

UK-EU-USA Charger included (based on delivery address)

Expected lifetime: 800-1000 cycles expected lifetime (approximately 3 years)

Free Shipping to UK, EU & USA

Fixed rate based on location for other regions.

All Swytch Product hold a 1 Year Warranty as standard. We do not expect you to have any problems installing or using your new Swytch Kit. However, should you have any problems, please do not hesitate to contact us at support@swytchbike.com and a Swytch Team Member will help you and if required provide you with the returns information.

IN-LINE Brake Sensors

In stock

$30.00
